Very High Temperature, Heat, Flame & Abrasion Resistant
Thermal Insulating Vermiculite Coated Fiberglass Tape
Thermal Insulating Vermiculite Coated Fiberglass Tape
Very High-Temperature Vermiculite Coated Fiberglass Tape
This high temperature, heat, flame and abrasion resistant thermal insulating vermiculite coated fiberglass tape will withstand temperatures of 1500°F / 815°C continuous exposure. The base High Temperature braided fiberglass sleeving is fabricated from high quality type E fiberglass that will not burn. The sleeve is then coated with a vermiculite dispersant.
This material resists most acids and alkalis and is unaffected by most bleaches and solvents. It is highly flexible and conformable.
The base fiber is manufactured to the specifications of ASTM D-578, ASTM committee D13, and subcommittee D13.18.
This material resists most acids and alkalis and is unaffected by most bleaches and solvents. It is highly flexible and conformable.
The base fiber is manufactured to the specifications of ASTM D-578, ASTM committee D13, and subcommittee D13.18.
Applications for this product include thermal insulation and/or protection of wires, cables, hoses, pipe and tube, as well as affording energy savings and personnel protection. Also used as a gasket or seal tape for doors and access panels.
The vermiculite coating also adds abrasion resistance to the sleeve.
The tape is available in Plain and Drop Warp Styles. Drop Warp tape has several of the center lengthwise yarns missing during weaving, and allows the tape to be easily used for bolt-hole applications (sometimes called ladder tape).
The vermiculite coating also adds abrasion resistance to the sleeve.
The tape is available in Plain and Drop Warp Styles. Drop Warp tape has several of the center lengthwise yarns missing during weaving, and allows the tape to be easily used for bolt-hole applications (sometimes called ladder tape).
Part Number T-FG-VC
Extreme environments require extreme solutions... high temperature heat protection
firesleeve, tapes, fireblankets, fabrics, ropes & gaskets for industry, aerospace,
marine, and military use from the industry leader in thermal protection solutions.
> Protects hydraulic / pneumatic hoses & lines, cables & wiring
> Reduces failures, unscheduled outages, maintenance & energy costs
> Provides protection to personnel from hot process piping & equipment
firesleeve, tapes, fireblankets, fabrics, ropes & gaskets for industry, aerospace,
marine, and military use from the industry leader in thermal protection solutions.
> Protects hydraulic / pneumatic hoses & lines, cables & wiring
> Reduces failures, unscheduled outages, maintenance & energy costs
> Provides protection to personnel from hot process piping & equipment
