Extreme High Temperature Tapes: Slit; Folded & Stitched; Woven
· Manufactured in 25' / 7.6m and 50' / 15.2m lengths.
· Thickness is 0.090" / 2.28mm.
· Slit from Silica Cloth roll - 1800°F / 982°C constant use.
· Wide range of standard widths - Other widths available upon request.
· Pressure sensitive adhesive available.
· Edges will unravel if pulled or handled often as there is no binder in the tape
· Thickness is 0.090" / 2.28mm.
· Slit from Silica Cloth roll - 1800°F / 982°C constant use.
· Wide range of standard widths - Other widths available upon request.
· Pressure sensitive adhesive available.
· Edges will unravel if pulled or handled often as there is no binder in the tape
· Manufactured in 25' / 7.6m and 50' / 15.2m lengths using 0.090" / 2.28mm thick slit cloth.
· 2 layers used for 1/8" thick tape, 3 layers for 3/16" thick tape, and 4 layers for 1/4" thick tape.
· Slit from Silica cloth roll - 1800°F / 982°C constant use.
· Wide range of standard widths - Other widths available upon request.
· Pressure sensitive adhesive available.
· 2 layers used for 1/8" thick tape, 3 layers for 3/16" thick tape, and 4 layers for 1/4" thick tape.
· Slit from Silica cloth roll - 1800°F / 982°C constant use.
· Wide range of standard widths - Other widths available upon request.
· Pressure sensitive adhesive available.
Woven Tape:
Extreme High Temperature Silica Tape is used commonly as a seal or gasket tape on furnace and kiln doors gas turbine engines and boilers. Silica has excellent burn through resistance when exposed to molten metal splatter from welding or cutting operations, and is a much superior material to fiberglass.
Part Number T-S-ST
Part Number T-S-FT
Part Number T-S-W
Slit Tape:
Folded & Stitched Tape:
· Easy to wrap over a 90° bend without buckling.
· Manufactured in 100' / 30.4m lengths.
· 1/8" thick tape, or folded and sticthed version is 1/4" thick.
· High purity silica yarn for 1800°F / 982°C constant use.
· Standard widths only
· Pressure sensitive adhesive available.
· Manufactured in 100' / 30.4m lengths.
· 1/8" thick tape, or folded and sticthed version is 1/4" thick.
· High purity silica yarn for 1800°F / 982°C constant use.
· Standard widths only
· Pressure sensitive adhesive available.
