Very High Temperature, Heat, Flame & Abrasion Resistant
Vermiculite Coated Fiberglass Tadpole Tape and Gasket
Vermiculite Coated Fiberglass Tadpole Tape and Gasket
Very High-Temperature
Vermiculite Coated
Fiberglass Tadpole Gasket
Vermiculite Coated
Fiberglass Tadpole Gasket
This high temperature, heat, flame and abrasion resistant vermiculite coated fiberglass (fibreglass or glassfibre) tadpole tape will withstand temperatures of 1500°F / 815°C continuous exposure. The base High Temperature fiberglass fabric is fabricated from high quality type E fiberglass that will not burn. The fabric is then coated with a vermiculite dispersant.
This material resists most acids and alkalis and is unaffected by most bleaches and solvents. It is highly flexible and conformable.
The base fiber is manufactured to the specifications of ASTM D-578, ASTM committee D13, and subcommittee D13.18.
The bulb material can be Fiberglass Rope, Stainless Steel Mesh or Inconel Mesh.
Typical applications for this seal and gasket tadpole tape are for gate valves; oven, furnace and kiln door and access cover gaskets.
This material resists most acids and alkalis and is unaffected by most bleaches and solvents. It is highly flexible and conformable.
The base fiber is manufactured to the specifications of ASTM D-578, ASTM committee D13, and subcommittee D13.18.
The bulb material can be Fiberglass Rope, Stainless Steel Mesh or Inconel Mesh.
Typical applications for this seal and gasket tadpole tape are for gate valves; oven, furnace and kiln door and access cover gaskets.
- Tadpole GasketAvailable widths (Over-All Width): 1", 1.250", 1.500", 1.750", 2.000",
2.500" and 3.000".
- Tadpole Gasket Bulb diameters: 3/8, 1/2, 5/8, 3/4 and 1".
- Tadpole Gasket Standard lengths: 50 and 100 feet
CUSTOM SIZES AVAILABLE.
2.500" and 3.000".
- Tadpole Gasket Bulb diameters: 3/8, 1/2, 5/8, 3/4 and 1".
- Tadpole Gasket Standard lengths: 50 and 100 feet
CUSTOM SIZES AVAILABLE.
Part Number:
TT-FG-VC
TT-FG-VC
