Very High Temperature Heat Resistant Wire Jacketed
Fiberglass Rope, Seal and Gasket
Fiberglass Rope, Seal and Gasket
Wire Jacketed Fiberglass Seals
High temperature wire jacketed fiberglass (fibreglass or glassfibre) seal and gasket provides superior abrasion resistance in oven, furnace, stove and kiln door applications. Supplied cut to length, each seal can be custom fabricated from a wide variety of diameters and configurations to provide the precise thickness and depth of seal for each U channel design specification.
Pre-engineering each seal insures a simple, labor saving solution to the problem of containing heat. This efficient design reduces fuel consumption and eliminates cold spots in brick/tile kilns which can cause some of the brick or tile to be underfired.
Very High Temperature Wire Jacketed Fiberglass Rope Seal and Gasket is fabricated from high quality type E fiberglass that will not burn and will withstand continuous exposure to temperatures of 1100°F / 593°C. This material resists most acids and alkalis and is unaffected by most bleaches and solvents. It is highly flexible and conformable. The base fiber is manufactured to the specifications of ASTM D-578, ASTM committee D13, and subcommittee D13.18. The seals are then jacketed with a knitted 30 stainless steel wire mesh, providing significant abrasion resistance.
Pre-engineering each seal insures a simple, labor saving solution to the problem of containing heat. This efficient design reduces fuel consumption and eliminates cold spots in brick/tile kilns which can cause some of the brick or tile to be underfired.
Very High Temperature Wire Jacketed Fiberglass Rope Seal and Gasket is fabricated from high quality type E fiberglass that will not burn and will withstand continuous exposure to temperatures of 1100°F / 593°C. This material resists most acids and alkalis and is unaffected by most bleaches and solvents. It is highly flexible and conformable. The base fiber is manufactured to the specifications of ASTM D-578, ASTM committee D13, and subcommittee D13.18. The seals are then jacketed with a knitted 30 stainless steel wire mesh, providing significant abrasion resistance.
Benefits of our High-Temperature Fiberglass Heat Protection Products
Fiberglass offers excellent heat resistance, retaining more than half of its room temperature tensile strength at 675°F / 357°C, and more than 25% at 875°F / 468°C. It begins to soften at 1500°F / 815°C and melts near 2050°F / 1121°C. Non-combustible and excellent thermal conductivity to dissipate hot spots; high resistance to chemicals and unaffected by UV light.
Fiberglass offers excellent heat resistance, retaining more than half of its room temperature tensile strength at 675°F / 357°C, and more than 25% at 875°F / 468°C. It begins to soften at 1500°F / 815°C and melts near 2050°F / 1121°C. Non-combustible and excellent thermal conductivity to dissipate hot spots; high resistance to chemicals and unaffected by UV light.
Part Number S-FG-SWJ
Very High Temperature
E Fiberglass Based
E Fiberglass Based
1100°F / 593°C Continuous
